Product overview
LF314 is a prismatic LiFePO4 battery module platform for battery system integration. Review the configuration-specific electrical ratings before selecting a module for your project.
Key features
- EVE LF314 — LiFePO4 prismatic, 314 Ah
- Multiple voltage and capacity configurations
- Integration planning for OEM battery systems
Configuration options
| Configuration | Nominal voltage | Nominal capacity | Calculated nominal energy |
|---|---|---|---|
| 1P8S | 25.6 V | 314 Ah | 8.0384 kWh |
| 2P4S | 12.8 V | 628 Ah | 8.0384 kWh |
P denotes parallel groups and S denotes the series arrangement. Configurations with the same nominal energy can have different voltage and amp-hour capacity.
Nominal energy shown here is calculated as nominal voltage × amp-hour capacity ÷ 1,000. It is not a measured usable-energy rating.
Dimensions, weight, current limits and BMS compatibility should be confirmed for the selected configuration. The Specifications tab lists the stored reference attributes for 1P8S.
System integration
Discuss the required operating voltage, charge and discharge current, charger, BMS interface and installation conditions with our team. Application suitability depends on the complete system configuration.
Discuss your project
Share your application, target voltage, installation space and estimated quantity. Discuss your battery project →
